MERIDA eOne-Forty 700 Anthracite / Black 2023
Pricing
Our Price £5650.00
Offer £4520.00
NOW 20 % / £1130.00 below RRP!
| Model Year | 2023 |
|---|---|
| Options | M Anthracite/Black (Item# 4710949836153 N832) In Stock (Warehouse) L Anthracite/Black (Item# 4710949836146 N833) Out Of Stock XL Anthracite/Black (Item# 4710949836177 N834) In Stock (Warehouse) XXL Anthracite/Black (Item# 4710949836184 N835) In Stock (Warehouse) |
| Style | High spec aluminium full suspension eBike. 630Wh battery and 85Nm Shimano EP8 motor. FOX Rhythm 34 Float 140mm fork RockShox Deluxe Select + shock. Shimano SLX and XT componentry. The eOne-Sixty is the headline grabber of the Merida eBike range; for 3 generations it's been winning tests gathering accolades and generally hogging the limelight! The eOne-Forty shares exactly the same frame and design features but has different ride characteristics. The shock stroke on the eOne-Forty is shorter reducing rear travel to 133mm and creating a steeper seat angle. The shorter 140mm fork extends the reach delivering a slightly steeper head angle. In combination these small changes make the eOne-Forty more agile and playful; a highly competent climber that's perfect for all day riding. The mixed wheel size set up is carried over to give the e-full suspension bikes precise steering fantastic 'rolling over obstacles' behaviour yet maximum traction a 29er front wheel with a 2.5 tyre is combined with a 650B rear wheel equipped with a slightly wider 2.6 tyre. The perfect combination of precision playfulness and traction. All eOne-Forty models use the powerful Shimano EP8 85NM motor and bigger 630Wh battery (with the exception of frame size - S which uses 504Wh). Shimano's e-Tube app allows you to tailor power delivery to suit your riding style; you can set two profiles; one for shredding and one for cruising. |
| Frame | Lite III - Hydroformed 6061 Double butted aluminium with integrated battery. Internal cable routing via Smart entry ports. Tapered head tube, 148 x 12mm axle standard. Max. tyre size 27.5" x 2.8". |
| Forks | Fork FOX Rhythm 34 Float eMTB+; Air; 140mm travel; Tapered; 51mm fork offset. Max. tyre size: 29" x 2.5" Shock RockShox Deluxe Select+; platform |
| Rear Derailleur | Shimano XT RDM8100 Shadow+ 12 speed |
| Shifters | Shimano Deore SL-M6100 12 speed with Shimano SL -MT500-IL lever |
| Chainset | Shimano CRE80-12-B; 34 tooth chainring with Shimano FCEM600; 165mm length crank |
| Bottom Bracket | Part of Shimano Steps motor |
| Chain | KMC e12T EPT |
| Freewheel/Cassette | Shimano M6100; 10-51 teeth; 12 speed |
| Headset | Merida-8152 |
| Stem | Merida Expert eTR II; aluminium; 35mm diameter; 0 degree rise - stem length: 50mm all sizes; GoPro & Supernova mount |
| Handlebars | Merida Expert eTR; 780mm wide; 20mm rise |
| Front Brake | Shimano SLX 4 piston hydraulic disc brake caliper with Shimano RT64 203 mm rotor |
| Rear Brake | Shimano SLX 4 piston hydraulic disc brake caliper with Shimano RTEM600 203 mm rotor |
| Brake Levers | Shimano SLX |
| Rims | 29" / 27.5" Merida Expert TR; 29mm inner rim width; aluminium; Tubeless ready (tubeless tape and valves not included) |
| Front Hub | Shimano SLX; 110x15mm; 32 spokes; Center lock |
| Rear Hub | Shimano SLX; 148x12mm, 36 spokes; Center lock; including removable lever with 4/6mm Allen key |
| Spokes | Black stainless |
| Tyres | Front Tyre Maxxis Rekon; 29" x 2.4"; Kevlar bead, folding; 3C EXO MaxxTerra Rear Tyre Maxxis Rekon; 27.5" x 2.6"; kevlar bead; TR 3C EXO MaxxTerra |
| Saddle | Merida Expert CC with V-mount including Merida minitool |
| Seatpost | Merida Expert TR; 30.9mm diameter; in-line; Drop: 100mm (S), 125mm (M), 150mm (L/XL), 170mm (XXL) |
| Pedals | VP Components - VPE-527 |
| Grips | Merida Expert EC |
| Miscellaneous | Front Light Lezyne eBike Power STVZO E115 Rear Light USB REAR Light CG-214RG Complete with: mini fenders and front / rear lights. Shimano Satellite charging port; EW-CP100 |
| Motor | Shimano Steps EP8; 85Nm |
| Battery | Shimano E8036; 630Wh internal battery Charger Shimano EC-E8004; 4A Charging current |
| Controls | eBike Display Shimano SC-E7000 Power Button Shimano satellite system on/off; EW-SW300 Mode Switch Shimano SW-E7000-L |
As with any product, specification is subject to change without prior notification. You are advised to confirm current specification before buying.
